GE Bottom-Freezer PDS20MBSWW
PDS20MBSWW
GE Profile Energy Star 19.5 Cu. Ft. Bottom-Freezer Drawer Refrigerator
Features
Upfront, Electronic Touch Temperature Controls with Digital Temperature Display Clearly displays the exact temperature for the fresh food and freezer compartments
ClimateKeeper System Best Temperature Management System You Can Buy!
Multi-Level Slide n’ Store Basket System Includes three full-extension baskets for tremendous storage flexibility and keeps contents perfectly in place
BrightSpace Interior with GE Reveal Lighting Cast a natural-looking glow throughout the refrigerator
ShelfSaver Rack Provides convenient storage for a 12-pack, two egg cartons or a 9″ by 13″ casserole dish
QuickSpace Shelf Quickly slides out of the way to make room for tall items
Self-Closing Drawer Self-closing hinges automatically pull the drawer shut when it’s within one inch of the closed position
Specs:
APPROXIMATE DIMENSIONS(HxDxW)
68 in x 33 7/8 in x 29 7/8 in
CAPACITY
Total Capacity (cubic feet)
19.50
Fresh Food (cubic feet)
13.21
Freezer (cubic feet)
6.31
Shelf Area (sq. ft.)
24.44
FEATURES
Defrost Type
FrostGuard
Energy Star-Qualified
Yes
Air Tower
Multiflow
Electronic Sensors
Yes - 3
TurboCool Setting
Yes
Upfront Electronic Digital Temperature Display
Yes
Upfront, Electronic Touch Temperature Controls
Yes
Automatic Icemaker
Optional (IM4A)
Ice Storage Bin
Integrated
Fresh Food Cabinet Shelves - Adjustable
4 Split
Fresh Food Cabinet Shelves - Slide-Out
2
Fresh Food Cabinet Shelves - Spill Proof
3
Fresh Food Cabinet Shelves - Total Number of Shelves
4 Glass
QuickSpace Shelf
Yes
Fresh Food Door Bins
5 (4 Adj. Split; 1 Full-Width Fixed)
Gallon Door Storage
Yes
Easy-Out Crispers
Pivot-Out
Meat Pan
Adjustable Temperature
Vegetable / Fruit Crisper(s)
2 Adjustable Humidity
Dairy Compartment
Yes
Interior Light
GE Reveal
Snugger Clip(s)
Yes
Freezer Interior Light
GE Reveal
Freezer Storage Basket
3 Sliding (2 Full-Width/1 Split)
Sweet Spot Shelf
Yes
Door Alarm
Yes
ECONOMICAL / QUIET
NeverClean Condensor
Yes
Cabinet Liner
ABS
Door Liner
ABS
Quiet Package
Premium Quiet Design
APPEARANCE
Color Appearance
White on White
Handle
Color-Matched
Door Swing
Reversible Hinges
Door Stops
Yes
Easy to Remove Door Gaskets
Yes
Leveling System
Yes
WEIGHTS & DIMENSIONS
Approximate Shipping Weight
265 lb
Net Weight (lbs.)
239 lb
Overall Depth
33 7/8 in
Overall Height
68 in
Overall Width
29 7/8 in
Case Depth Without Door (in.)
28-1/4
Depth with Door Open 90 (in.)
59
Depth Without Handle (in.)
31-3/4
Height to Top of Case (in.)
67-1/4
Width w/Door Open 90 Degrees Inc. Handle (in.)
33-1/4
Width w/Door Open 90 Degrees Less Handle (in.)
31-1/8
Back Air Clearances (in.)
1
Side Air Clearances (in.)
1/8
Top Air Clearances (in.)
1
POWER / RATINGS
Volts / Hertz / Amps
120v; 60Hz; 15A
ACCESSORIES
Optional Icemaker Kit
IM4A
WARRANTY
One Year Warranty
Entire Appliance; Parts & Labor: In-Home
Full Five Year
Sealed System; Parts & Labor; In-Home
